Atcom A41/41W Executive level IP Phone

Made for manager level users in the office

A41/A41W is a 4 SIP accounts, multiple features, easy deployment, and Wi-Fi optional IP Phone, which has 3.2-inch FSTN 4 level grey LCD, 4 soft keys, 8-speed dial programmable keys extending to 88 keys, convenient operation performance, and TIA920 high definition wideb and voice standard, with clear HD voice. It is designed for business level enterprise unified communication application


Top level voice quality

WIFI + cable connection enable flexible deployment

Dual core CPU is the guarantee of high quality IP phone


One core for instruction process and the other core for voice
decoding greatly improve the sound quality and make it possible
to run more complicated applications fluently.


Basic functions
Graphic LCD at 4 level grey, 244*128 Pixel, 4 SIP accounts, Call Forward, Call Transfer, Call Waiting, Hotline, Call Hold, Auto Answer, Caller ID, Redial, Mute, DND, Local 3-Way Conferencing, Speed Dial, Voice Mail, Local Phonebook (upto 400), Direct IP call without SIP proxy, Black list, White list, Dialed/Rece ived/Missed/Forward call (total 400), Call Center Headsets mode,support EHS Headset

Configurable through web interface/phone, Provisioning: Auto-provision via FTP/TFTP/HTTP/HTTPS, DHCP Option 66,PnP, Redirection and Provisioning Service(RPS)

IP PBX Features
Intercom, Paging, Call pickup, Call park, Anonymous call, Anonym ous call rejection, Hold on music, Conference Call, Group pickup, DND&Call forward state synchronization, Call Recording

Power Interface: DC 5V-1A, PoE power supply: IEEE 802.3af Class 2 2x RJ45 100/1000M adaptive Ethernet ports, 1x RJ9 headphone jack, 1x RJ9 handset jack

English, German, Italian, French, Spanish, Portuguese, Russian, Chinese, Arabic, Polish, Turkish ? Hebrew

Keys Features
1 status indicator, 4 line keys, 4 soft keys, 5 navigation keys, 1 vo lume keys, 8 function keys (menu, cancel, hold, voicemail, mute, headphone, redial, hands-free)

Advanced Features
LDAP, Microsoft active directory(AD) server, XML remote phonebook,TR069,Action URL

Temperature and Humidity
Operating temperature: -10 ~ 50°C, Operating humidity: 10 ~ 90%

Audio Features
8 own ring tone, 2 custom ring tone article, 8 volume adjustable + Mute mode, Narrowband codec: G.711(a/?), G.729A/B/AB, G.726, iLBC, Wideband codec: G.722, L16, Support VAD, CNG, AEC, PLC, AJB, AGC, Full-duplex speakerphone with AEC

Configurable through web interface/phone, Provisioning: Auto-provision via FTP/TFTP/HTTP/HTTPS, DHCP Option 66, Redirection and Provisioning(RPS)

Network Features
LAN / PC: support bridge mode,Span to PC, Open VPN , SIP connection mode: Proxy mode, and P2P mode, Support DNS SRV (RFC3263). NAT transverse: STUN mode. DTMF: In-band, RFC2833, SIP INFO, Support QoS, IPv4&IPv6 , HTTP / HTTPS web server, Package tracing export, Syslog

Qty/CTN: 10 PCS , G.W/CTN: 15KG, Giftbox size: 325 m m(L)*210mm ( W ) *80mm(H) Carton Meas: 425mm(L) *415mm(W) *345mm(H)

WiFi Features(A41W only)
IEEE 802.11b/g/n, Enhanced support for IEEE 802.11e QoS,  IEEE802.11i (WPA, WPA2) authentication

CE: EN60950 FCC: Part15

VLAN, LLDP, IEEE802.1X, TLS, HTTPS, SRTP (RFC3711), Digest authentication using MD5/MD5-sess, AES encryption for configuration file s, Phone lock, User and administrator level access control


A41/A41W Models PoE Wifi Gigabit
A41W Y Y N
